Row Crop Tractors
6R Row Crop Tractors
145 to 250 hp. With 20 percent more interior space and a host of other new features, row crop and hay producers won't find a more versatile tractor.
| Model | Engine HP¹ | PTO HP | Transmission | Hydraulics |
|---|---|---|---|---|
| 6R 110 | Engine HP: 90kW (121 HP) Max/82kW (110 HP) Rated with up to 20 additional HP (IPM) |
62 kW (83 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h |
Standard: 45 cc pump: 114 L/min (30 gpm) |
| 6R 120 | Engine HP: 98kW (132 HP) Max/89kW (120 HP) Rated with up to 20 additional HP (IPM) |
68 kW (91 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h |
Standard: 45 cc pump: 114 L/min (30 gpm) |
| 6R 130 | Engine HP: 107kW (143 HP) Max/97kW (130 HP) Rated with up to 20 additional HP (IPM) |
75 kW (101 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h |
Standard: 45 cc pump: 114 L/min (30 gpm) Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 140 | Engine HP: 115kW (154 HP) Max/104kW (140 HP) Rated with up to 20 additional HP (IPM) |
82 kW (110 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h |
Standard: 45 cc pump: 114 L/min (30 gpm) Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 145 | Engine HP: 119kW (160 HP)/Max 108kW (145 HP) Rated with up to 40 additional HP (IPM) |
84 kW (113 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h, 24-speed Direct Drive 40 km/h and 50 km/h |
Standard: 45 cc pump: 114 L/min (30 gpm) Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 155 | Engine HP: 126kW (171 HP) Max/116 (155 HP) Rated with up to 40 additional HP (IPM) |
91 kW (122 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h, 24-speed Direct Drive 40 km/h and 50 km/h |
Standard: 45 cc pump: 114 L/min (30 gpm) Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 165 | Engine HP: 136kW (182 HP) Max/123kW (165 HP) Rated with up to 40 additional HP (IPM) |
96 kW (129 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h |
Standard: 45 cc pump: 114 L/min (30 gpm) Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 175 | Engine HP: 144kW (193 HP) Max/130kW (175 HP) Rated with up to 40 additional HP (IPM) |
102 kW (137 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h, 24-speed Direct Drive 40 km/h and 50 km/h |
Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 195 | Engine HP: 160kW (215 HP) Max/145kW (195 HP) Rated with up to 40 additional HP (IPM) |
116 kW (156 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h, 24-speed Direct Drive 40 km/h and 50 km/h |
Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 215 | Engine HP: 177kW (237 HP) Max/160kW (215 HP) Rated with up to 40 additional HP (IPM) |
130 kW (174 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h, 24-speed AutoQuad™ PLUS ECO 40 km/h and 50 km/h, 24-speed Direct Drive 40 km/h and 50 km/h |
Optional: 60 cc pump 155 L/min (41 gpm) |
| 6R 230 | Engine HP: 189kW (253 HP) Max/172kW (230 HP) Rated with up to 40 additional HP (IPM) |
137 kW (184 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h |
Standard: 85 cc pump 160 L/min (42 gpm) |
| 6R 250 | Engine HP: 205kW (275 HP) Max/186kW (250 HP) Rated with up to 40 additional HP (IPM) |
150 kW (201 hp) |
Standard: Infinitely variable transmission (IVT™) 40 km/h, Optional: IVT 50 km/h |
Standard: 85 cc pump 160 L/min (42 gpm) |
7R Row Crop Tractors
210 to 350 engine hp. The 7R Row Crop Tractors have high power density because of their low overall machine weight and high horsepower rating. Couple that with the FT4 engine and the efficiency features found on IVT and e23™ transmissions, makes these tractors an excellent choice for transport applications such as silage or manure hauling because they provide fast acceleration and low total fluid economy.
| Model | Engine kW (HP) | Loader Option | Transmission Options | Suspension |
|---|---|---|---|---|
| 7R 210 | 157 (210) |
CommandQuad™ Eco with Efficiency Manager; e23™ PowerShift with Efficiency Manager; available John Deere IVT™ |
Available Triple Link Suspension Plus (TLS), ActiveSeat™ II, or Air Seat plus adjustable Cab Suspension |
|
| 7R 230 | 172 (230) |
CommandQuad™ Eco with Efficiency Manager; e23™ PowerShift with Efficiency Manager; available John Deere IVT™ |
Available Triple Link Suspension Plus (TLS), ActiveSeat™ II, or Air Seat plus adjustable Cab Suspension |
|
| 7R 250 | 187 (250) |
e23™ PowerShift with Efficiency Manager; available John Deere IVT™ |
Available Triple Link Suspension Plus (TLS), ActiveSeat™ II, or Air Seat plus adjustable Cab Suspension |
|
| 7R 270 | 201 (270) |
e23™ PowerShift with Efficiency Manager; available John Deere IVT™ |
Available Triple Link Suspension Plus (TLS), ActiveSeat™ II, or Air Seat plus adjustable Cab Suspension |
|
| 7R 290 | 216 (290) |
e23™ PowerShift with Efficiency Manager; available John Deere IVT™ |
Available Triple Link Suspension Plus (TLS), ActiveSeat™ II, or Air Seat plus adjustable Cab Suspension |
|
| 7R 310 | 231 (310) |
e23™ PowerShift with Efficiency Manager; available John Deere IVT™ |
Available Triple Link Suspension Plus (TLS), ActiveSeat™ II, or Air Seat plus adjustable Cab Suspension |
8R/8RT/8RX Tractors
230 to 410 engine hp. The 8R/8RT/8RX Tractors are world-class machines designed to provide the hydraulic capacity and horsepower to handle large planters and implements. Powered by the PowerTech™ 9.0L engine, the 8R is a champion in the field, delivering uncompromised performance while meeting Tier 4 emission requirements.
| Model | Engine kW (HP) | Wheel/Track | Transmission Choices | Suspension |
|---|---|---|---|---|
| 8R 230 | 172 (230) |
Wheel |
16-speed PowerShift with APS; e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
Independent Link Suspension (ILS™) |
| 8R 250 | 187 (250) |
Wheel |
16-speed PowerShift with APS; e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
Independent Link Suspension (ILS™) |
| 8R 280 | 209 (280) |
Wheel |
16-speed PowerShift with APS; e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
Independent Link Suspension (ILS™) |
| 8R 310 | 231 (310) |
Wheel |
16-speed PowerShift with APS; e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
Independent Link Suspension (ILS™) |
| 8RT 310 | 231 (310) |
2-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
AirCushion™ Suspension and a true 4-Corner cab suspension |
| 8RX 310 | 231 (310) |
4-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
New 4-Corner cab suspension with +/- 4 inches of travel |
| 8R 340 | 254 (340) |
Wheel |
16-speed PowerShift with APS; e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
Independent Link Suspension (ILS™) |
| 8RT 340 | 254 (340) |
2-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
AirCushion™ Suspension and a true 4-Corner cab suspension |
| 8RX 340 | 254 (340) |
4-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
New 4-Corner cab suspension with +/- 4 inches of travel |
| 8R 370 | 276 (370) |
Wheel |
e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
Independent Link Suspension (ILS™) |
| 8RT 370 | 276 (370) |
2-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
AirCushion™ Suspension and a true 4-Corner cab suspension |
| 8RX 370 | 276 (370) |
4-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager; IVT™ available with new CommandPRO™ control |
New 4-Corner cab suspension with +/- 4 inches of travel |
| 8R 410 | 306 (410) |
Wheel |
e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control |
Independent Link Suspension (ILS™) |
| 8RT 410 | 306 (410) |
2-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control |
AirCushion™ Suspension and a true 4-Corner cab suspension |
| 8RX 410 | 306 (410) |
4-Track |
e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control |
New 4-Corner cab suspension with +/- 4 inches of travel |
| 8R 440 | 385 (440) | Wheel | e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control | Adjustable cab suspension and adjustable seat |
| 8RX 440 | 385 (440) | 4-Track | e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control | Adjustable cab suspension and adjustable seat |
| 8R 490 | 426 (490) | Wheel | e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control | Adjustable cab suspension and adjustable seat |
| 8RX 490 | 426 (490) | 4-Track | e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control | Adjustable cab suspension and adjustable seat |
| 8R 540 | 466 (540) | Wheel | e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control | Adjustable cab suspension and adjustable seat |
| 8RX 540 | 466 (540) | 4-Track | e23™ 23F/11R Powershift Transmission with Efficiency Manager or Electric Variable Transmission (EVT) with optional CommandPRO control | Adjustable cab suspension and adjustable seat |
